Sleek, aerobatic, and highly adaptable, the Teros™ from Navmar Applied Sciences Corporation is the perfect airframe for a multitude of UAV applications. Designed to meet the expanding requirement for an extended range, high altitude aircraft, the Teros can operate in a wide range of environments and excel at the most challenging missions.
The rugged and resilient Teros was derived from a proven airframe that has logged thousands of mishap-free flight hours. Its robust and unique construction makes it highly durable without adding unnecessary weight or sacrificing payload capacity. Putting it simply, the Teros is an American-Made solution that does the job at a fraction of the cost of similarly capable unmanned aerial vehicles.
Sleek, aerobatic, and highly adaptable, the Teros™ from Navmar Applied Sciences Corporation is the perfect airframe for a multitude of UAV applications. Designed to meet the expanding requirement for an extended range, high altitude aircraft, the Teros can operate in a wide range of environments and excel at the most challenging missions.
The rugged and resilient Teros was derived from a proven airframe that has logged thousands of mishap-free flight hours. Its robust and unique construction makes it highly durable without adding unnecessary weight or sacrificing payload capacity. Putting it simply, the Teros is an American-Made solution that does the job at a fraction of the cost of similarly capable unmanned aerial vehicles.
- The extraordinarily rugged Teros features robust and unique construction for high durability without unnecessary weight or loss of payload capacity.
- Teros offers the volume and power to fly substantial payloads.
- The Teros utilizes a proven motor glider airframe by Sonex Aerospace. The design offers a very low cost per flight hour and an exceptionally low overall life-cycle cost.
- Teros integrates critical redundant flight control systems and a smart electrical system to prevent complex failures.
The NASC Teros™ is a Group 4/5 UAS designed to be operated and fully integrated into the National Airspace System. Teros can fly the programmed mission autonomously and seamlessly within the air traffic control system. Teros achieves an exceptionally high level of Availability, Reliability, and Maintainability (ARM). The ARM process continues to be the primary evaluation criteria for all spiral upgrades, maintenance methods, and procedures.
Teros integrates critical redundant flight control systems and a smart electrical system to prevent complex failures. The surprisingly agile Teros features robust construction and durability without sacrificing its lightweight design. With short takeoff and landing capability, fast field assembly, rapid servicing, and autonomous flight operation, Teros is a highly versatile and highly capable aerial platform.
| A: Length | 20′ (6m) |
| B: Wingspan – High Altitude | 45′ 8″ (13.9m) |
| B: Wingspan – Normal Ops | 39′ 9″ (12m) |
| General Specifications | |
| Engine | 125 HP (Other options available) |
| Fuel Capacity | 50 – 90 gal. (189-341L) |
| Gross Takeoff Weight | 1,800 lbs. (816.5kg) |
| Payload Specifications | |
| Max. Payload Weight | Up to 600 lbs.* (272kg) |
| Frequencies | |
| All Frequencies | Please contact NASC at 215-675-4900 with your frequency questions. |
| Flight Performance |
|
| Max Altitude | Up to 24,000 ft. (7,315m) MSL* |
| Max Speed | 120 Kts* |
| Loiter Speed | 55 – 61 Kts |
| Launch and Recovery | Conventional wheeled take-off and landing (Improved and semi-improved runways) |
| Endurance | Up to 24 Hours (Payload/fuel dependent)* |
* Estimated – Actual value dependent on performance and/or integration of selected payload.
Teros™ applications and payloads include, but are not limited to, the following:
Aerial Surveillance/Surveying with Turret-based Digital
EO/IR (Thermal Camera) and Hyperspectral Imagers
- Disaster Response & Damage Assessment
- Law Enforcement/First Response
- Search and Rescue
- Fire Mapping
- Large Area Agriculture & Livestock Monitoring
- Natural Resource Management
- Utility Line Security and Monitoring
- Wildlife Conservation
- Emergency Delivery
Payload/Sensor Research & Development
- Turret Systems
- EO/IR Camera Sensors
- Synthetic Aperture Radar Systems (SAR)
- Microwave Imaging Systems
Communication and Communication Relay Platforms
- High Data Rate Software Defined Microwave Radio Systems
- Microwave Power Repeater Systems
- Antenna Arrays
- COMINT/SIGINT Systems
Laser Scanning Systems
- Geological & Terrain Mapping
- Oil, Gas and Mineral Exploration
- Utility Line Security and Monitoring
LIDAR Chemical Detection and Atmospheric Probing
- Environmental/Pollution Monitoring
- Aerial Spraying
- Meteorological Research
- Climate Research
Teros – Unmatched Capability and Military-Grade Performance
Teros Featured in FPL Super Bowl Commercial
